Amortyzatory Hijacker
Monroe : MA702
Nr artykułu: MNRMA702
Monroe Shocks & Struts Max-Air MA702 Air Shock Absorber
- Compressed Length: 12.625 IN
- Dust Shield Included: Yes
- Dust Shield Material: Rubber
- Extended Length: 20.75 IN
- Hydraulic Lockout: No
- Includes Bump Stop: Yes
- Internal Rebound Bumper: No
- Lower Mount Code: L1/CP4
- Lower Mount Type: Loop Bushing and Cantilever Pin Mount - 1/2" Stud Diameter X 1 1/2" Stud Length (Center of Loop to Frame)
- Part Description: Air Shock Absorber
- Parts Pack(s): (2) P00072
- Shock Absorber Body End Measuring Point: Center of Loop
- Shock Absorber Rod End Measuring Point: Center of Cross Pin
- Travel Length: 8.125 IN
- Upper Mount Code: XP7
- Upper Mount Type: Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.7/8" Pin Length (Hole Center to Center)
- 49152: Gabriel
- GAB39128: Replaced
- GAB49128: Replaced
- MA702: NAPA Shocks
